Complete Mineral Drinking Water Processing Shrink Wrap Packing Line Machine

• After-sales Service：7*11, Oversea Service Available
• Warranty：1 Year
• Processing Material：Animal Raw Materials, Forest Products, Special Agricultural Products, Garden Products, Agronomic Products, Natural Ingredients
• Application：Pet Food, Chocolate, Ice Cream, Vegetable, Fruit, Dairy, Beverage
• Customized：Customized
• Certification：CE, ISO9001

=== Base Info ===

• Model NO.：LC-MB6535
• Power Source：Electric
• Automatic Grade：Automatic
• Usage：Water Beverage Food Bottle Tin Can Carton Box
• Transport Package：Standard Export Packaging
• Specification：Machine Size L6000*3200*2100mm
• Trademark：Young Chance Pack
• Origin：China
• HS Code：8422400000
• Production Capacity：20 Pieces,Month

=== Description ===
Containers and specificationsProject Name: Full Automatic Complete Mineral Water 2000-20000bph Production LinePH≥4.6drinking watermaterialshapeFilling volume(ml)Filling level(mm)Neck typePET BottleSquare or Round Bottle100-2000mlDistance from bottle neck
According requestAs requestAdjustable specifications of the bottle typeMiddle Mould Base: Bottle diameter ≤105mm Bottle Height≤335mm Customers need to buy additional change-over parts for the different bottles.
If using square bottles, then bottle separating system will be added.Container Label & Control ModePackaging systemPalletizing systemHot Melt Roll-Fed
PVC Shrink Label
Full Label/ Half Label
Manual / AutomaticPacking systemMin, Spec.Manual
Low position gantry palletizer
Robot Palletizer
High position gantry palletizer
Single Arm Palletizer
Manual Palletizer Manual
Film shrinker
Wrap Around packer
Robert Packing Machine1*2
2*3
3*4
4*6
3*5 User Ambient Conditions:Temperature:10~40ºC;Humidity:No dewUser Electrical Supply SpecificationVoltage:380V±5%, 3phase; Frequency:50HZ±1%
PET circular or squareDia50-Dia115mm160-320mm0.3 MpaAseptic water>0.06Mpa <0.2mpa<>drink water bottling production line440*300*330 mmMachine Height2.1m2.1m2.1m2.5m2.5m2.5mWeight(kg)1200kg1500kg2000kg4000kg4500kg4500kg
Conveying Belt Width: 304 mm
Voltage/Power: 380V /19KW
Working Air Pressure: 0.6-0.8 Mpa
Air Consumption: 0.5 m3/minute Packaging Form:Upper and Lower Heat Shrink Film Sealing&Cutting (Double Row) Packaging Material : LDP
Specail solution for Auto Cardboard Sheet Placing+ Auto Shrink Film Wrapping.
Special solution for Auto Cardboard Tray Folding + Auto Shrink Film Wrapping.

Auxiliary machines


RO water treatment system

We adopt different equipment to produce pure water, mineral water etc. The main equipment of RO Water Treatment Plant are silica sand filter, active carbon filter, sodium ion exchanger, hollow fiber, RO( reverse osmosis), UV sterilizer, precision filter, ozone generator, water tank etc. It can effectively get rid of muddy organic matter, iron, manganese etc, reduce the hardness of the water to make all specifications of the water quality fully meet the state fresh water standard of fresh drink water.

Washing filling capping system

CGF Wash-filling-capping 3-in-1unit: Beverage Machinery is used to produce polyester bottled mineral water, purified water, alcoholic beverage machinery and other non-gas beverage machinery. Beverage Machinery can finish all the process such as washing bottle, filling and sealing, it can reduce the materials and Outsiders touch time, improve the sanitary conditions, production capacity and economic efficiency.
The Complete Bottled Mineral Water / Pure Water Production Line used in the beverage filling operations. The three functions of bottlewash, fill and seal are composed in one body of the machine. The whole process is automatic.

Blow molding system

1. Excellent Mechanical Strength, impact-resisting, and non-craking.
2. Bottle mouth and thread are of precise measurement.
3. Plastic Medicine Bottle's safe thread can be molding directly.
4. The size and weight of the product can calculate and design clearly and meet the requirement of the design without any deviation.
5. The surface of the bottle mouth, neck and the body is good luster and smoothness, the standard of bottle body is unity.
6. The joint seam on the bottle body is smooth, no scrap rubber.

Automatic labeling machine

1.Hot melt glue labeling machine is widely used for different material of container .
2.The label cost is comparatively lower, it can meet the requirements of those users who have diverse kinds of the containers.
3.It is the most economical models in cost to make mass production and intergrated operating.
4.The equipment has massively used modularization design concept to make it easy and simple for users to change the bottles.

 Order Information
To help us make sure this model is suitable for you, please kindly provide the following information with your inquiry:
1) Details of your product (Dimensions, Photos and Drawings)
2) Packaging Combination for each pack (2×3, 3×4, 4×6 or others)
3) Packaging Capacity Required (How many bottles/cans for each hour on the current/planned production line)
4) Packaging Expectation (Photo of packed product shall be very helpful)
5) Packaging Automation Level (Semi-automatic or Complete Automatic)
6) The Layout Drawing of workshop (Optional, just help us prepare arrangement of the machine)
7) The Height of current production line (Optional, just help us confirm the height of conveying system)8) Other usful information which might helpful.
