Plastic Pipe Making Machine for 75mm-250mm HDPE Water Pipe

=== Base Info ===

=== Description ===
Line ModelScrew DiameterL/DProduction ScopeLine Speed or OutputKDPE-25075mm36:175-250mm320kgs/h75-250mm HDPE Pipe Production Line Configuratoin:No.Machine Part NameQuantity175/36 Extruder with capaicty 320kgs/h1set2Material loader1set3Mateerial dryer1set4Small extruder for blue strips making1set5HDPE pipe die head and moulds (75-250mm)1set8Calibrators (75-250mm)1set9Vacuum Tank (1 set10Cooling Tank2 sets11Three caterpiller Haul-off machine (servo motor driven)1set12Dustless cutting machine1set13Pipe Stacker1set14PLC control system1set15Remote control device1set



1)Special designed high efficient five-section type screw and barrel, ensuring the rapid plasticizing & dispersion effect, and realizing high speed production.

2)Gravimetric material feeding system is to control material feeding according to pipe parameter & line production speed, to get high qualified pipe with constant weight per meter. It's also have other benefits, such as shortening start-up time, saving raw material, simplifying operation.
This is as an option, for big diameter we'd like to recommend you to consider in, to save raw material and short the start up time.

3)Spiral pressure-storage die head, ensuring the stability of high speed extrusion and produced pipe quality.
The die head is designed different as per pipe pipe structure and diameter range, like high speed extrusion die head, two layer co-extrusion die head or three layer -co-extrusion die head.

4) The haul-off machine is driven by SIEMENS servo motors; three caterpiller type driven by 3 numbers of servo motor. The haul-off speed is more stable.

5)SIEMENS PLC programmable computer control system, which could ensure the whole line high-speed synchronous control and its stable & reliable running.
And remote control device is equipped, to help analysis the machine problem if any.
