HDPE Plastic Processed and Extrusion Blow Moulding Blow Moulding Type Blown Film Extrusion ...

=== Base Info ===

=== Description ===

Basic Info.

Model NO. MD-ABA Machine Weight 4T Certification CE Transport Package Nude Packing Specification 4.5× 2.2× 6.5(meter) Trademark Mingde Origin China HS Code 8477209000 Production Capacity 30 Sets / Year

Product Description

Model	MD-ABA50,55
Suitable Material	HDPE,LDPE
Max Film Width(mm)	1200
Film Thickness(mm)	0.012-0.12mm
Max Extrusion Output	120kg/hr
Gear Box	146X1,173×1
Screw Diameter(mm)	φ50×1, φ55×1
Screw L/D Ratio	28:1
Screw's Material	38CRM(55
Barrel's Material	38CRM
Barrel's Cooling Fan	370W×2×2
Thermo Control (zone)	3×2
Driving Motor (kw)	18.5kwx1,22×1
Die Size (mm)	HD:φ150 LD250
Screen Changer	Normal
Thermo Control (zone)	3
Air Ring	1
Cooling Blower (kw)	5.5
Center Steady Stick	1
Roller Width (mm)	φ138×1300
Embossing Roller Width	700mm
Take-UP Motor (kw)	1.1
Take-UP Speed(M/min)	10-60
Height adjustable type	yes
Type OF Winder	Single winder with air shaft
Roller Width (mm)	1300
Winding Motor (N.M)	16
Winding Speed(M/min)	10-80
Voltage	380V,3P,50HZ
Cover Dimensions (m)	4.5×2.2×6.5
