350m Trailer Portable Water Well Drilling Rig

=== Base Info ===

=== Description ===

Basic Info.

Model NO. TZ-350 Bit Type DTH Drilling Way Impactor Type Crawler Power Hydraulic Configuration Portable Transport Package Export Standard Specification 5400x1800x2480mm Trademark TZ Origin Guangxi Liuzhou HS Code 8430412900 Production Capacity 100

Product Description

Our TZ series water well drill rig is uses full hydraulic control and the top drive to drive the rotation of drilling tools with very high drilling efficiency,Reasonable overall layout uses the tractor-mounted or all terrain chassis for the transportation with good maneuverability.very flexible in difficult roads,it can be widely used in many fields,such as resource exploration of hydrology wells,coal bed methane,shallow layer of shale gas,terrestrial heat,ect,and can also be used for coal-mine gas exploitation or salvage work.TZ series well drilling rig have been exported to many countries

The top-mounted driving head principal shaft have a great drift diameter,which is suitable for many kinds of construction work such as mud pump drilling,air drilling and air foal drilling,meeting the demands of well drilling in different terrain strata

ModelTZ-350
Max drilling depth350m
Drilling diameter105-325mm
Adaptation conditionF=6-20
Recommendation Working pressure1.2-3.5MPa
Recommendation air consumption16-55m3/min
Drill Rod length3/6 m
Drill rod diameter89/102mm
Maximum propulsion6.5T
Maxumum lifting force16T
Fast forwarding speed55m/min
Fast lifting speed30m/min
Maximum  Rotation speed80/160r/min
Maxumum rotation torque7000/3500Nm
Drilling speed10-35m/h
Winch lifting force1.1T
Working speed2.5km/h
Grade ability21
High leg stroke1.6m
Dimension5400x1800x2480mm
Drilling methodAir drilling  or Mud pump drilling
Engine85Kw
Total weight8.2T

Our component list:
350m Trailer Portable Water Well Drilling Rig

Products display:
350m Trailer Portable Water Well Drilling Rig
350m Trailer Portable Water Well Drilling Rig

350m Trailer Portable Water Well Drilling Rig

350m Trailer Portable Water Well Drilling Rig
