Glorystar Ipg 1000W-3000W Fiber Metal Laser Cutting Machine GS-3015

Xingyuan Plastic Manufacturing Co., Ltd / 2022-06-23

Glorystar Ipg 1000W-3000W Fiber Metal Laser Cutting Machine GS-3015

  • Application:Agriculture Machinery, Automotive Industry, Advertising Industry, Metal Processing
  • Cooling System:Water Cooling
  • Technical Class:Continuous Wave Laser
  • Applicable Material:Metal
  • Structure Type:Gantry Type
  • Laser Classification:Fiber Laser

=== Base Info ===

  • Model NO.:GS-3015
  • Laser Technology:Laser Fusion Cutting
  • Model No.:GS-3015
  • Laser Type:Fiber Laser Generator
  • Working Area:3000mm*1500mm
  • Laser Wavelengh:1064nm
  • Rated Output Power:500W,1000W,2000W,3000W,4000W
  • Cooling Mode:Water Cooling
  • Maximum Load of Worktable:800kg
  • Minimum Line Width:0.15mm
  • G.W.:7t
  • Color:Red-White-Black
  • Transport Package:Packed in Piaywood
  • Specification:CE, SGS, FDA, Bureau, ISO
  • Trademark:GLORYSTAR
  • Origin:China
  • HS Code:84561090
  • Production Capacity:5000PCS,Years

=== Description ===
3015Maximum material width (mm)3000×1500X axis travel (mm)1520Y axis travel (mm)3020Z axis travel (mm)80X/Y axis positioning accuracy±0.05mm/mX/Y axis repeat positioning accuracy≤0.04mmMaximum positioning speed140m/minMaximum acceleration1.2GSlit width0.1-0.5mm(Measured value below 3mm thickness)Incision roughnessRa3.2-Ra25.4(Measured value below 3mm thickness)Maximum cutting thickness rangeRefer to the craft parameter tableMinimum setting unit0.001mmFloor area of machine tool (mm)6000×3000Host volume (mm)4850*2250*1700CNC systemCypCutMonitor19″LCDTransfer methodGear rack dual driveMaximum load-bearing capacity of worktable (tons)1Machine weight (tons)3Total installed power consumption (approximately)Laser power:1000W17kWLaser power:1500W19.5kWLaser power:2000W22kWPower requirementsAC380V,50Hz;3P+N+PETotal power protection levelIP54
 Cutting Samples

Glorystar Ipg 1000W-3000W Fiber Metal Laser Cutting Machine GS-3015
>>> After-sale Service

Installation and debugging
Technicians can be sent to the factory for training (free of service fee for the first time). Customers only need to provide accommodation for engineers.
Training
Free of charge for training within warranty. But customers need to take charge of the cost for accommodation, air tickets, visa fee.
24/7 online service
All our laser equipment is provided with 12 months warranty. Glorystar Laser offers free maintenance or replacement service if something is wrong with the equipment under warranty. If it is out of warranty,Glorystar Laser will send engineers to your factory as soon as possible and only charge the cost of parts.
Accessories supply
IPG laser source is 2 years. Other parts is one year except for optical and consumable parts. Prolong serve is always available for option. Free of charge for fixing and changing parts within warranty. Only changing parts , the freight should be charged by customers.
Remote diagnosis
Glorystar Laser can check the running status of the customer's laser cutter through our remote maintenance system. Our technicians can perform troubleshooting via remote access instead of on-site diagnosis and maintenance, saving you a lot of time.
Additionally, Glorystar Laser will establish a special user profile for all customers who have purchased equipment from us to record your usage, maintenance records and other information. This will help us to learn about customer information more quickly and thus provide necessary upgrades according to customer feedback



Glorystar Ipg 1000W-3000W Fiber Metal Laser Cutting Machine GS-3015
ABOUT GLORYSTAR LASER

Glorystar Laser Technology Co.,Ltd. is a high-tech enterprise combining state-of-the-art technologies to develop and produce high power laser cutting machines. We have the manufacturing capabilities to produce 500W-30000W metal laser cutters to satisfy the diverse needs of our customers. Our main product types include tube fiber laser cutting machine, sheet fiber laser cutting machine, tube and sheet combined fiber laser cutting machine, all cover exchange platform laser cutting machine, single table fiber laser cutting machine and so on.

Our group operates four companies, each of them can complete equipment assembly and debugging independently, and ensuring timely delivery for customers. Today, Glorystar Laser has more than 8000 cooperative clients in over 130 countries around the world, including America, England, Italy, Argentina, Thailand, Malaysia, and so on.


CERTIFICATION

200+ R&D TEAM

Glorystar Ipg 1000W-3000W Fiber Metal Laser Cutting Machine GS-3015



Glorystar Ipg 1000W-3000W Fiber Metal Laser Cutting Machine GS-3015

RESEARCH ROOM

In addition, our company has been cooperating with many universities for a long time to establish the "Laser Application Research Institute" and the "Intelligent Manufacturing Research Institute" for deep research on laser applications and intelligent manufacturing applications.


Glorystar Ipg 1000W-3000W Fiber Metal Laser Cutting Machine GS-3015Glorystar Ipg 1000W-3000W Fiber Metal Laser Cutting Machine GS-3015
