Mini Type Blow Machine

=== Base Info ===

=== Description ===

Basic Info.

Model NO. QS-MN50 Machine Weight 1.8t Certification CE Material HDPE&LDPE Die Size 60-80mm Screw Material Sacm-645/38 Crmoala Output 30/40kgs Transport Package Seaworthy Specification CE SGS Trademark QUEENSENSE Origin China HS Code 847730900 Production Capacity 30-80kgs/H

Product Description

It is used to blow low density polyethylene (LDPE), high density polyethylene (HDPE) and linear low density polyethylene (LLDPE) plastic films and other films, and is widely used in civil and industrial package such as food, clothes, garbage bags and T-shirt bags.

Model	QS-MN45	QS-MN50
Suitable material	HDPE/LDPE	HDPE/LDPE
Film width	100-500mm	100-600mm
Film thickness	0.008-0.1mm	0.008-0.1mm
Max. Extrusion output	30kg	40kg
Screw diameter	45	50
Screw  L/D Length	28:1	28:1
Screw Material	Sacm-645/38 Crmoala	Sacm-645/38 Crmoala
Driving motor	11kw	11kw
Die size	50-70mm	60-80mm
Roller Width	600mm	700mm
Type	steel roller-friction type rewinder	steel roller-friction type rewinder
Winding speed	5-50m/min	5-50m/min
Outline Dimension(L*W*H)	2300*1800*3000mm	2300*1800*3000mm
Weight	1.9T	2.1T
