Micro Foamming Machine Suitable for Producing Heat-Preservation Cups

=== Base Info ===

=== Description ===

Basic Info.

Model NO. PU20J-W Transport Package Plywood Box Specification 2500*1500*2500mm Trademark ZCE Origin China HS Code 8477800000 Production Capacity 50/Month

Product Description

ZCE specialized in doing Polyurethane foam machine, Pu roller making machine, Polyurethane wheel and castor making machine, Polyurethane elastomer machine, MDI/TDI/NDI Polyurethane machine, Polyurethane injection machine, Polyurethane two components pouring machine,Three components polyurethane pouring machine, Polyurethane casting machine, PU machine, Polyurethane roll machine, Resin Casting Machine.

Product Photo

Parameters and Applications

Parameters:

ITEM/MODEL	PU20J-W1	PU20J-W2	PU20J-W3	PU20J-W4
(A:B) Mixing Ratio	3:1	3:1	3:1	3:1
Total Discharge Amount(g/min)	1-3.5	2-8	6-18	10-30
Rotational Speed of Circle	15-100	15-100	15-100	15-100
Pouring Head Stirring Speed(r/min)	4000-6000	4000-6000	4000-6000	4000-6000
External Dimension (L*W*H)(mm)	1400*1100*2000	1400*1100*2000	1400*1100*2000	1400*1100*2000
Total Power (KW)	6	6	7	8

Applications: used in such miniature polyurethane products as hard foam,semi hard foam,sell-skin formed foaming.high resilience and slow resilience, which are aplied to:heat pres- ervation cups,instrument bobbeers,toys,shoulder pads and insoles etc.they may be also used in ingredient tests by colleges and research bodies.

Features
1. Applicable to the manufacture of hard rubber and semi-hard rubber of flter, such as the two- -side end covers of flter, oill flter paper adhesion and safety pad of air filter etc.
2.Using nellient digital display meter. temperature error ≤ ± 1ºC.
3. High- temperature resistant low- speed high- precision metering pump; accurate matching, flexible adjustment and measurement accuracy error of less than ±0.5%. The rate of grated product is guaranteed.
4. The precise dynamic mixing head is suitable for the unitform mixing of PU glue of all viscosities, applicable to foaming. sealing, casting fling and adhesive etc.
