Double-Layer PE Coextrusion Film Blowing Machine

=== Base Info ===

=== Description ===

Basic Info.

Model NO. QS-2G50/55/60 Machine Weight 4T Certification CE, ISO9001:2008, QS Film Thickness 0.028-0.2mm Max.Extrusion Output 180kg/H Driving Motor 18.5-30kw Winding Speed 5-50m/Min Size 5.6*2.8*5.5m Transport Package Seaworthy Specification CE SGS Trademark QUEENSENSE Origin China HS Code 847780000 Production Capacity 1000PCS/Per Years

Product Description

This machine is applied to manufacturing printed or uncolored T-shirt bags made of HDPE, LDPE roll film. It adopts double stepping (servo) motor fixed length, and the feeding, sealing, cutting, punching holes and transporting are completed only in one process. It is of high degree of automation and good economic results.


Model	QS-2G50	QS-2G55	QS-2G60
Diameter of screw	50× 2	55× 2	60× 2
L/D	28: 1	28: 1	28: 1
Reduced diameter of film(mm)	800	1000	1200
Single-face Thickness of film(mm)	0.015-0.10	0.015-0.10	0.015-0.10
Max. Output(kg/h)	40	65	80
Power of main motor(kw)	11× 2	15× 2	18.5× 2
Heating Power(kw)	26	30	42
Outline diameter(L× W× H)(mm)	4200× 2200× 4000	4600× 2400× 4600	5000× 2800× 5000
Weight(T)	4	5	6
