Plastic Squeezed Ground/Agriculture/Packaging LDPE LLDPE 98/95 Film Granulating Line
Dongguan Yize Precision Cutting Tool Co., Ltd. / 2022-07-04
=== Base Info ===
=== Description ===
Model | Diameter of screw | PE capacity | PP capacity |
TSDJ-100 | Φ100mm | 100-150kg/h | 90-120kg/h |
TSSJ-100/100 | Φ100/100mm | 100-150kg/h | 90-120kg/h |
TSDJ-120 | Φ120mm | 200-250kg/h | 180-200kg/h |
TSSJ-120/120 | Φ120/120mm | 200-250kg/h | 180-200kg/h |
TSDJ-150 | Φ150mm | 280-350g/h | 250-300kg/h |
TSSJ-150/150 | Φ150/150mm | 280-350g/h | 250-300kg/h |
TSDJ-180 | Φ180mm | 380-420kg/h | 320-360kg/h |
TSSJ-180/180 | Φ180/180mm | 380-420kg/h | 320-360kg/h |
TSDJ-200 | Φ200mm | 450-500kg/h | 380-400kg/h |
TSSJ-200/200 | Φ200/200mm | 450-500kg/h | 380-400kg/h |
For Hard Plastics
TC Series Plastic PE PP Film Granulating Line Model | Diameter of screw | PE capacity | PP capacity |
TCDJ-85 | Φ85mm | 150-200kg/h | 100-150kg/h |
TCSJ-85/85 | Φ85/85mm | 150-200kg/h | 100-150kg/h |
TCDJ-100 | Φ100mm | 280-350kg/h | 250-300kg/h |
TCSJ-100/100 | Φ100/100mm | 280-350kg/h | 250-300kg/h |
TCDJ-130 | Φ130mm | 480-550kg/h | 400-500kg/h |
TCSJ-130/130 | Φ130/130mm | 480-550kg/h | 400-500kg/h |
TCDJ-160 | Φ160mm | 650-800kg/h | 600-750kg/h |
TCSJ-160/160 | Φ160/160mm | 650-800kg/h | 600-750kg/h |
TCDJ-180 | Φ180mm | 800-1200kg/h | 750-1000kg/h |
TCSJ-180/180 | Φ180/180mm | 800-1200kg/h | 750-1000kg/h |
For Soft Films

(The thickness of granules is depend on the speed of cutter)360°services:Customer requirements →Scheme designed →confirmed by customers →order fixed →manufacturing →trial running in our factory →confirmed by customers →shipped →engineer available overseas →whole life after sales servicesHow to choose single stage or double stage?Common:The same feature between single and double stage pelletizing machine is they can all extrusion the plastics. They can all recycle the waste plastics into plastic granules.Difference:* Single stage granulating line is with one stage, double stages granulating line is with two stages extruders.
* Single stage granulaying machine is usually to process clean and dry plastics, double stages granulating machine is usually to process dirt and wet plastics.(Mositure less then 8%)
*You can choose single or double stages according to the material is dirty or clean. Normally, double stage with 2 filtrations system will stop more impurities.
*In all, we can customzied your machines according to different situations.
