- Power Source:Electric
- Process:Thermal Processing
- Warranty:One year
- After-sales Service:One year
- Certification:CE, ISO9001
- Automatic Grade:Semi-Automatic
=== Base Info ===
- Specification:ISO9001: 2008,HACCP,GMP
- Transport Package:Wood Package and Framework
- Brand:Beyond
- Certificate:ISO9001:2008,HACCP,GMP
- Control Type:Automatic
- Material:SUS304,316L
- Customized:Customized
- Application:Milk
- Model NO.:500L-500000L,D
- Trademark:BEYOND
- Origin:China
- HS Code:8438200000
- Production Capacity:100 Processing Lines Each Year
=== Description ===
Overview
Equipment list of 25T/D Dairy processing equipment
(pasteurized milkyogurtcheesecreamutter)
| | | | | |
NO. | NAME | SIZE | MAIN TECHNOLOGY PARAMETER | UNIT | QTY |
1 | MILK RECEIVESTORAGEAND CREAM SEPARETOR UNIT | | |
2 | electron pound scale | | maximum weighing 500KG | set | 1 |
3 | milk weighing tank | 350L | made of SUS stainless steal,single layer,product feeded in through 40 mesh filter net,CIP cleaning ball | set | 1 |
4 | milk acceptor | 500L | SUS304 stainless steel,single layer,CIP cleaning ball | set | 1 |
5 | milk pump | 5T/h | SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished | set | 1 |
6 | twin piping filter | 5T/h | SUS304 stainless steel,two pipe,Stainless Steal Filter Element 100 Mesh | set | 1 |
7 | dish separator | 5T/h | auto residue discharge | set | 1 |
8 | chiling tank | 5000L | SUS304 stainless steel,alveolate jacket,attached with compressor | set | 4 |
9 | milk pump | 5T/h | SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished | set | 1 |
10 | PREPARING UNIT | | |
11 | blending tank | 2500L | SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet | set | 2 |
12 | milk pump | 5T/h | SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished | set | 2 |
13 | mini set of plate-type heat exchanger | 5T/h | SUS304 stainless steel,two stages, | set | 1 |
14 | high speed emulsification tank | 600L | SUS304 stainless steel,heat insulated,bottom high speed emulsifier,digital readout thermometer,supporters with adjustable feet | set | 1 |
15 | milk pump | 5T/h | SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished | set | 1 |
16 | twin piping filter | 5T/h | SUS304 stainless steel,two pipe,Stainless Steal Filter Element 100 Mesh | set | 1 |
17 | sterilizing,homogenizing unit | | |
18 | UHT sterilizer | 2T/h | tub-type,sterilzing temperature 137 C,holding time 4S,full automatic control | set | 1 |
19 | high pressure homogenizer | 2T/h | 40MPa,(starting box included) | set | 1 |
20 | temperature holding | 2T/h | SUS304,holding 300S | set | 1 |
21 | distributing plate | | SUS304,3 holes | set | 1 |
22 | cheeseutter processing unit | | |
23 | bufferying tank | 2500L | SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet | set | 1 |
24 | milk pump | 5T/h | SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished | set | 1 |
25 | cream seperator | 1T/h | | set | 1 |
26 | bufferying container | 200L | SUS304,with cover | set | 2 |
27 | milk pump | 3T/h | SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished | set | 2 |
28 | butter-churner | 150L | SUS304,stepless timing | set | 1 |
29 | cheese vat | 1500L | SUS304,with heating jacket and insising device | set | 1 |
30 | pressor | | SUS304,6 heads | set | 1 |
31 | mould | | SUS304,10L,with cover | set | 30 |
32 | yogurt fermentation unit | | |
33 | fermentation tank | 2500L | SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet | set | 3 |
34 | rotary pump | 10T/h | SUS304 stainless steel,Hard Alloy Mechanical Seal,manual stepless shift | set | 1 |
35 | plate cooler | 10T/h | SUS304,single stage,milk discharge at 4C | set | 1 |
36 | rotary pump | 1T/h | SUS304 stainless steel,Hard Alloy Mechanical Seal,manual stepless shift | set | 1 |
37 | filling unit | | |
38 | higher position tank | 1000L | SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet | set | 1 |
39 | pasteurized milk filling machine | | | set | 1 |
40 | yogurt filling machine | | | set | 1 |
41 | CIP system | | |
42 | semi-auto CIP system | 4×1T | outer coat of SUS304 stainless steel material,inner shell of SUS316,single cleaning way,Concentrated acid/alcali tank adding system based on US technology, 100L×2 acid/alcali Concentrate tanks | set | 1 |
43 | CIP return pump | 20T/h | SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished | set | 4 |
44 | | | installation part | | |
Company Profile
Our ServiceTrade shows
Certificate
Packaging & Shipping
FAQ
1 ) Q: How can we visit your factory?
A: If you come from abroad, air to shanghai airport, then we can pick you up at airport.
2) Q: How do you ensure the quality of your products?
A: Our Company is a state owned enterprise with more than 16 years experience , strict operation policy is performed, advanced processing machines guarangtee the precision of all components, workers with operation license, parts get multiprocessing, transmission& electrical parts are of international famous brand. Series of test and inspection are done in the whole producing state.
3) Q: What payment methods your company accept?
A: We accept most of the payment methods , but mainly accept T/T, L/C at sight .
4) Q: How long is the warranty time for your products?
A: Our officially promised warranty time is 12 months after commissioning .
5) Q: I am new in this field,can you supply us turnkey services?
A: YES.We can supply all the system including Market Analysis/Product Analysis/Location Choice/Processing Flow Design/Equipment Layout Design/Building Design direction/Equipment mode selection/Equipment Manufacturing/Equipment Mounting/Equipment Debugging/Worker Training.
6) Q: What ' s the shipment terms and delivery time of your company?
A: Well, the delivery time depend on the quantity of your order. Usually is 20 days . For some customized machine 30 days is necessary.
7) Q: Can you supply OEM services?
A: Yes,we have our R&D team,and we have more than 400 workers with workshop area 75000 square meters.
8) Q: Do you give any Discount?
A: I will surely try my best to help you get those by the best price and good service at the same time.
