1000L 1500L 2000L 5000L 10000L Conical Beer Fermenting Tanks Jacketed Beer Fermentation ...

• Condition：New
• Customized：Customized
• Voltage：110V-480V Customized
• Composition：Fermentation Tank
• Processing Material：Special Agricultural Products, Malt,Yeast,etc
• Process：Ferment

=== Base Info ===

• Model NO.：HG-2000L
• Model：Hg-Fj-2000L
• Capacity：Useful Capacity;5bbl; Gross Capacity;6.25bbl
• Material：SUS304
• Application：Restaurant, Bar, Hotel, Brewery
• Cooling Method：Jacket Section Cooling
• Thickness：Inner:3.0mm; External2.0mm
• Outrigger：Ø102mm*4
• Test Pressure：0.2MPa
• Working Pressure：0.09MPa
• Heat Exchange Area：1.9m2
• Weight：310kg
• Transport Package：Plywood Case by LCL or Container by FCL
• Specification：500L ,1000L ,1500L ,2000L
• Trademark：HG
• Origin：Shandong

=== Description ===

Basic Info.

Model NO. HG-2000L Model Hg-Fj-2000L Capacity Useful Capacity;5bbl; Gross Capacity;6.25bbl Material SUS304 Application Restaurant, Bar, Hotel, Brewery Cooling Method Jacket Section Cooling Thickness Inner:3.0mm; External2.0mm Outrigger Ø102mm*4 Test Pressure 0.2MPa Working Pressure 0.09MPa Heat Exchange Area 1.9m2 Weight 310kg Transport Package Plywood Case by LCL or Container by FCL Specification 500L /1000L /1500L /2000L Trademark HG Origin Shandong

Product Description

Model	HG-FJ-2000L
Capacity	Useful capacity:2000L; Gross capacity:2500L
Material	SUS304
Application	Restaurant, bar, hotel, brewery
Cooling method	Jacket section cooling
Thickness	Inner:3.0mm; External2.5mm
Outrigger	Ø102mm*4
Test pressure	0.2Mpa
Working pressure	0.09Mpa

Product advantages :
1. 304 stainless steel plate as a whole, and our stainless steel plate manufacturer is the best in China
2. The cooling efficiency of Maitreya plate jacket is greatly improved.
3. Two stage cooling mode.
4. The insulation layer material is high-grade polyurethane with a thickness of 80mm.
5. Polishing accuracy up to Ra0.4μ m.
6. Strict tank pressure test.
7. Energy conservation and pollution emissions.

The fermentation tanks use certified stainless steel material. All tanks and jackets inspected and pressure
tested to 3 times operatiing pressure. The dimension of the tanks can be designed according to customer's
requirement. Tank design pressure is 0.4Mpa and testing pressure is 0.3Mpa.






Item	Production capacity	Volume in US Gallon	Heating area	Tank diameter	Height
HG-100	100L/day	26US Gallon	0.5m2	650mm	1500mm
HG-200	200L/day	53US Gallon	0.8m2	850mm	1600mm
HG-300	300L/day	79US Gallon	1.2m2	960mm	1700mm
HG-400	400L/day	106US Gallon	1.5m2	1060mm	2000mm
HG-500	500L/day	132US Gallon	1.8m2	1160mm	2300mm
HG-5BBL	5BBL/day	155 US Gallon	1.9m2	1200mm	2350mm
HG-600	600L/day	158US Gallon	2.0m2	1220mm	2350mm
HG-700	700L/day	185US Gallon	2.4m2	1260mm	2380mm
HG-800	800L/day	212US Gallon	2.5m2	1260mm	2400mm
HG-7BBL	7BBL/day	216US Gallon	2.5m2	1280mm	2450mm
HG-1000	1000L/day	264US Gallon	2.6m2	1360mm	2500mm
HG-10BBL	10BBL/day	310 US Gallon	2.8m2	1460mm	2700mm
HG-1500	1500L/day	396US Gallon	3.2m2	1520mm	2900mm
HG-2000	2000L/day	528US Gallon	3.6m2	1560mm	2850mm
HG-2500	2500L/day	660US Gallon	3.8m2	1650mm	3200mm
HG-3000	3000L/day	792US Gallon	4.5m2	1760mm	3800mm
HG-4000	4000L/day	1057US Gallon	4.9m2	1900mm	4100mm
HG-5000	5000L/day	1320US Gallon	7.2m2	1960mm	4400mm

Our service

1.Pre-service:
-Layout:Sent us your building floor plan, or the sketch, or tell us the size (length, width, height), we will offer you an equipment footprint according to your requirement.
-Technical Drawings : We will offer Technical Drawings of each tank based on the equipment layout .
-3D effective sketch: We will 3D effective sketch to make sure ensure you have a more intuitive experience
2.After service
We guarantee the quality of the electrical elements within 1year and tanks body within 1 years. If the electrical elements go wrong without artificial factors within one year, we will freely provide them or maintain them for you.
After warranty, if you need to change parts, we will kindly provide you with the best price or maintain it in your site. Whenever you have technical question in using it, we will freely do our best to support. We can also dispatch our engineer to your brewery to install and adjust the machines for you. He can also train your staff to use the equipment.


FAQ


Q: Are you a manufacturer?
 A:Yes, We have more than 22 years in brewing and beer filling equipment.
Q: What is your available port of shipment?
A: Qingdao, Tianjin, Ningbo, Shanghai
Q: How could we confirm the details of the products?
A: We will provide all the drawings for you to confirm before production.
Q: How long the warranty will be?
A: 6 years warranty for the whole tank and the main equipment, 1 year for the accessories and auxiliaries.
Q: How about the installation and training?
A: We can supply the installation and training. There are two options. The first option: We could appoint our engineer to your company to debug and repair, as for the cost of this trip such as ticket, visa, accommodation and labor cost shall be on your side. The second option: On-line service will be provided. If still under guarantee period, the necessary accessories and parts will be provided free, the buyer afford the transportation cost.
Q: How do you guarantee the filling machine operation?
A: Before the delivery, we will test and debug all machines in good condition and record the video for your checking.
The price does not include electrical appliances, etc.
