Diceing Materials Filling Full Automatic Capers Filling Machine

• Type：Whole Line
• Voltage：380V
• Power：Customized
• Customized：Customized
• Model No.：Lw
• Product Name：Canned Food Production Line

=== Base Info ===

• Model NO.：LW
• Packaging：Tin, Glass
• Automatic Grade：It Can Be Customized According to The Output
• Dimension(L*W*H)：Customized
• Usage：Plastic, Tin, Glass
• Transducer：Danfoss
• Electrical Elements：Schneider
• Warranty：1 Year
• Power Supply：3pH 380V 50,60Hz
• Application：a Variety of Canned Fruits and Vegetables
• Certificate：Ce SGS Ios
• Feature：Easy to Clean
• Material：Stainless Steel
• Advantage：The Operation Is Simple
• Transport Package：Wooden Case
• Specification：customized
• Trademark：lw
• Origin：Shanghai
• HS Code：190709000
• Production Capacity：10 Set,Year

=== Description ===
4)Automatic packing partEmpty cans depalletizerUsed to depalletizer cans automaticllyWashing machineEmpty cansAutomatic peach filling machine without weight + lifting conveyor + guard bar + staircase + come In and out of the conveyorDifferent diameter will need change rotate platformFilling sugar soup  Iron cans Capping machineSealing Can(400g)
Different diameter different costSterilization and cooling
Roller conveyor model Drying machine Labeling MachineHorizontal wet glue Sticker labelPrint MachinePrint date(VIDEOJET)Automatic carton erector  Automatic carton packer Used to pack serveral cans into carton
Different diameter will need change mould, cost is 3,500USD/setCarton SealingUse tapeAutomatic carton palletizer Used to pallet carton on the pallet automaticllyRoller conveyorWith power Roller conveyorWithout power Chain conveyorW=152.4mm (Length by your ideas)Driving system for conveyor  some installing pictures:


our control system

some descriptions of our machineCooling machineExcept Motor and  bearings ,other standard parts are made of stainless steel SUS304 / 2B material, in full compliance with the export of food hygiene requirements.
This machine series are suitable for all kinds of vegetables,fruits, fungi's pre-cooking and cooling of the product.Precook temperature and speed can be set according to the technical requirement.
The machine uses SUS304 stainless steel chain plate,  mesh belt,mesh belt with high intensity, small scale, difficult deformation, easy maintenance, etc., the
whole machine balanced running, low noise, greatly improving the work efficiency
This machine is heating mode of electric heating.The machine transmission system adopts gear motor speed regulation  which
make the conveyor belt speed adjustable.
 Selecting conveyorApply to primary raw materials selecting and cutting treatment.
The machine adopts disassembly design.Quantity of working station can be customized according to clients'actual demand.
The whole machine adopt SUS304 stainless steel.  1.1  Lifting conveyor main body side chain plate:Plate thickness:δ2.0mm Material:SUS304.
When produced according to the actual size.

1.2 Roller:Material  SUS304,diameter is based one the actual
load,cooperate with the plus or minus tolerance.
1.3 Riding wheel:Material  Nylon processing molding,diameter is based one the actual load,cooperate with the plus or minus tolerance.
1.4 Bun foot:Nylon injection molding,Cooperate with stainless steel adjusting screw M16.
1.5 Guardrail part adopts big Caluminum trackCooperate with wear-resisting sheath;
1.6 Connecting plate:plate wicknessδ3.0mm Material:Stainless steel bending forming;
1.7 Connection between mesh belt:Nylon board or ball, according to the customer's product selection.
1.8 Accessories:Mounted Bearings,kinds of SUS304 screws,etc.
Conveying carrier part
2.1 Module length:According to the effective length*widthness (mm)(When produced according to the actual size);
2.2 Module belt varieties:Flat grid, grid, according to the actual situation to choose material.
2.3 Material:POM,PP,PE
2.4 Color:White,Blue,Green.
3.Power system
3.1 Gear motor:Worm gear and worm gear motor,
Protection class IP55,Power P=1.5KW/0.75KW;
3.2 Speed:V=0-25 Meter/MIN;
3.3 Speed choice: Denmark Danfoss inverter frequency control motor speed.
4.1 Electric cabinet material:1.5mm SUS304 Stainless steel plate bending welding forming.
4.2 Electronic components:disconnector,AC contactor, button switch,etc.       Brand: Schneider,France.
can washing
Descriptions:
It is applied to clean and dry outside surface of all kinds of canned fruit,canned meat,bottled sauce and all kinds of drinks.(specializedin washing and drying the adhensive sugar water and other adhenion outside of the sealed canned products or beverage), applying for tin cans,glass bottles and plastic bottles.
Machine features:
The whole machine adopts SUS304 stainless steel manufacturing, reduce pollution, ensuring healthyof the products.
High degree of automation, automatic tempreture control, good finish washing.
Using Acrylic hood, the whole cleaning process can be seen.
Double cleaning design, washing water can be recycled.
Advanced machine design structure,easy to clean,water tank large diameter drain hole.
Parameters:
Capacity: 50-100cans/min,stepless speed.
Pipeline speed:6-30m/min
Scope of application:Cans Dia 40-180mm,height:40-200mm
Size:4600*800*1400mm
Motor:0.75kw, 10-50 r/min
Sanitary pump:0.75kw*6  12.5T/h
Fan:7.5kw*2
certificate




FAQ
Q1:Are you manufacturer or trading company?
We are manufacture verified by ALIBABA and we have our own design team.
Q2:Where are you located? Is it convenient to visit you?
We are located in Shanghai. Traffic is very convenient.
Q3:How can you guarantee quality?
1.We have completed working system and procedures and we follow them
very strictly.
2.Our different worker is responsible for different working process, their work
is confirmed,and will always operate this process, so very experienced.
3.The electrical pneumatic components are from the world famous companies,
such as Germany's Siemens, Japanese Panasonic etc.
4.We will do strict test running after the machine is finished.
5.Our machines are certified by CE,SGS,ISO.
Q4:Can you design the machine according to our requirements?
Yes. We not only can customize the machine according to your technical
drawing, but also can design new machine according to your requirements.
Q5:Can you offer overseas technical support?
Yes. We can send engineer to your company to set the machine and train your
worker if needed.
