Coconut Oil Pressing Equipment

• Type：Spiral Oil Press
• Application：Coconut
• Voltage：380V
• Appearance：Horizontal
• Press Materials：Copra
• Press Series：Fifth

=== Base Info ===

• Condition：New
• Customized：Customized
• Low Residual Oil Rate：6%-8%
• Transport Package：Moisture-Proof Packing
• Specification：2900mm*1850mm*3240mm
• Trademark：Huatai
• Origin：Henan
• HS Code：8479200000
• Production Capacity：20000sets,Year

=== Description ===

Basic Info.

Condition New Customized Customized Low Residual Oil Rate 6%-8% Transport Package Moisture-Proof Packing Specification 2900mm*1850mm*3240mm Trademark Huatai Origin Henan HS Code 8479200000 Production Capacity 20000sets/Year

Product Description

Coconut Oil Pressing equipment


Product Description

Process flow for coconut oil pressing machine

Copra---metering conveyance---magnetic selector---grinding---cooking---prepressing---cake crushing---disctribution screw conveor---twice pressing---filtration---crude pressing oil.

1. Metering conveyance: adopt metering feeder to convey copra at certain quantity,
2. Magnetic selector: use magnetic selector to remove metal impurities.
3. Grinding machine: Crush bigger copra, increase superficial area and convenient for pressing oil, cracking them into smaller pieces.
4. Copra cooking machine: Use steam cooker,heat with steam, with stirring blade, to make flakes become matured, and increase oil yield.
5. Copra oil prepressing machine: Use spiral oil press to physically press oil from oilseeds, oil yield is high, residual oil rate in cake is low, cake quality is good.
6. Twice pressing machine: because of high oil content, after prepressing, crushing cake and press again to get the oil at minimum quantity.
7. Copra oil filter: Use filter to remove cake powder and other impurity from oil to make oil clear.











Spiral coconut oil press is one kind of continuous oil press.It's suitable for pressing various oilseeds, such as soybean,peanut,rapeseed,sunflower seed,sesame,cottonseed,corn germ, niger seed and so on. It has the following advantages:

1. High capacity
2. Low power consumption
3. Low cost in running
4. Small occupation area
5. The structure of the press cake is soft but not fragmentary.
6. Low residual oil in cake.
7. Excellent choose of press equipment for the large and medium-sized oil plant.

Coconut oil press details:
Steel casting, squeezing bar and worm quenching process, wear-resistance
The thickness of pressing cake is adjustable, convenient maintenance,
Semi-open type reducer,stable running, cake outlet with cake crushing device, squeezing shaft can be input cooling circulating water,improve cake quality, the whole oil press is sealed, energy-saving and beautiful.
 Technical Parameters

Model	Processing capacity	Residual oil rate	Power (kw)	Overall dimensions (L*W*H)	Weight (kg)
ZY18	7~10T/D	5~7%	18.5	2900*1850*3240mm	5000
ZY24	15~20T/D	7~9%	38.5	2900*1850*3640mm	5500
ZY28	40~60T/D	7~9%	70	3740*1920*3843mm	9160
ZY32	90~100T/D	8~10%	106.5	4100*2270*3850mm	1100
ZY120	6.5T/D	≤6.5%	11	1860×622×1275mm	680
ZY130	8~10T/D	≤8.0%	15	1950×742×1500mm	825
ZY140	9~11T/D	≤8.0%	18.5	2010×690×1430mm	806
ZY168	20T/D	≤7.0%	37~45	2670×1000×1726mm	1710

Specification: 10T/D----100T/D (daily processing capacity)

Machining Work
We have 210 senior engineering technicians among 580 staff, invest USD60,000.000 to establish 8 production workshops, 2 machining workshops,with 202 sets of automatic processing equipment, such as automatic laser cutting machine, flame cutting machine, double housing planer,union melt welding machine, tube-sheet welding machine, etc, annual processing capacity is more than 3000 sets.







Company Information
Henan Huatai Cereals and Oils Machinery Co., Ltd. ,outstanding membership enterprise of CCOA,also public company in oil machine field in China.We are a large scale oil machinery manufacturer integrating research, development, design, manufacture and installation.We have self-supported import and export right and has passed ISO9001:2008 Quality Management System Certification.Registered trademarks"Huatai" and "Hangpeng" won Henan provincial famous brand,and was awarded "Provincial outstanding quality products".

We have successfully obtained 29 national patents (including 9 invention patents), 6 international awards, 2 national awards and 2 provincial awards. Our oil machines sell well in more than 30 provinces, cities and districts, and exported to Estonia, Russia, Kazakhstan,Uzbekistan,Tajikistan,Malaysia, Indonesia, Egypt, Bangladesh, Myanmar, the Philippines,Nigeria, Sudan, Tanzania,Rwanda,Bolivia,Peru and other countries, and now we have developed into a major oil machinery manufacturing base in China.



 Rich experience of large overseas projects

• Hundreds of successful overseas projects;
• Rich experience in government bidding projects;
• Products are exported to all over the world;
• Large project experience, can undertake 3,000t/d projects;

Packing & Delivery
Packing: Our oil machines adopt wooden case or power distribution cabinet and motors, reducers, and adopt solid packing for flanges, meters, valves,etc.
For all machines, after sand blasting and rust protection, also use film to keep cleaning before delivery, also fixing treatment to prevent rolling and collision.
Technical Support
1.Our factory is located in Huaxian County,our factory covers an area of 100000m2, with 8 standard processing workshops, 202 sets of machining equipment, 580 staff, 12 intallation teams.

2.Our trademark "Hangpeng" win TOP 10 oil machine brand, because of excellent product quality and perfect after-sale service.

3.We have successfully obtained 29 national patents (including 9 invention patents), 6 international awards, 4 national awards and 2 provincial awards.

4.We have the most complete production certificates of oil machines, such as "Design license of pressure vessel","Manufacture license of pressure vessel","Design license of pressure pipeline","Installation,reconstruction and maintenance license of pressure pipeline", "Manufacture license of organic heat carrier furnace" and installation certification of mechanical and electrical equipment".

4. We are outstanding member enterprise of CCOA (Chinese Cereals and Oils Association), so we produce machines according to standard, and refined oil reaches the best edible oil standard.

5.We have strong R & D team, production team and installation team, offer perfect after-sale service, after delivering goods, we will dispatch technicians to instruct installation, commissioning and train your workers to operate machines by  yourselves.

6.We are provincial enterprise abiding by contracts and keeping promises, we have produced oil machines for 65 years, with rich experience and own brand, so we are responsible for all of our projects, especially for oversea projects.

7.Overseas projects: we are establishing every perfect overseas sample project all over the world, such as Estonia, Russia,Ukraine Kazakhstan,Uzbekistan,Tajikistan, Indonesia, Thailand, Bangladesh, Myanmar,Cambodia,the Philippines,Egypt,Ethiopia, Kenya,Tanzania, Rwanda, Congo, Cameroon,Nigeria, Bolivia,Peru,etc.
